CD Structural Plywood

An E0 rated engineered wood panel for high-strength applications and offered in various stress grades, CD Structural Plywood is the backbone of our plywood range.

Certified under AS/NZS 2269:2012 for structural reliability, DBM's CD grade structural plywood is designed for visible applications. It features a ‘C’ face grade with a sanded finish, including puttied knots and splits, while the ‘D’ back grade remains unsanded and unputtied. For uses where appearance isn’t a concern, a ‘DD’ structural plywood option is also available.

On request, DBM’s CD structural plywood can be treated with specific preservatives for protection against termites and environmental wear.

Applications

Often used in retail shop fittings, office interiors and cafes, CD Structural ply achieves an industrial design. Additional applications:

  • Underlay for Solid Timber Floors

  • Truck Bodies

  • Pallets & Crates

  • Retail Fit-out

  • Dog Kennels, Cubby Houses, Bird Aviaries

  • Commercial Construction

  • Residential Projects

  • Wall & Ceiling Linings

  • Soffit Linings

  • Building Site Hoardings

  • 2400×1200mm

    2700×1200mm

  • 7mm, 9mm, 12mm, 15mm, 17mm, 19mm, 21mm, 25mm

    Additional thicknesses available upon request

  • FSC® A000521

    The mark of responsible forestry.

  • Standards

    AS/NZS 2269:2012 Plywood - Structural

  • Bond Strength

    Type A

    Phenol-formaldehyde Resin

  • Face/Back Grade

    C-face
    D-back

    BB, BC, CC, DD available upon request

  • Stress Grade

    F8, F11, F17

  • Treatment Level

    H2S, H2 and H3-ACQ
    Available on request

  • Density

    >600kg/m3
